Camera Specification
| Feature | Specification |
|---|---|
| Image Sensor | 1/2.8″ Back-Illuminated SONY IMX CMOS sensor |
| Color Type | Color |
| Illumination | 0.01 Lux @ (F2.0, AGC ON); 0 Lux with IR Light |
| Digital (DSP) | Yes |
| Wide Dynamic Range (WDR) | 120 dB |
| Lens Mount | M12 |
| IR Range | 30 m |
| Warm lights | 2 LED Warm lights |
| Resolution | 2560 x 1440 |
| Minimum Video Compression | H.265/H.264/H.265+ / MJPEG |
| Auto Gain Control | Yes |
| Bit Rate Control | CBR / VBR |
| Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
| Audio Compression | G.711ulaw, G.711alaw, G.722.1, G.726, MP2L2, PCM, MP3, AAC |
| Simultaneous Live View | Up to 6 channels |
| Supported Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, NTP, SMTP, IGMP, IPv4, IPv6, UDP, ARP, SNMPAPI: ONVIF, ISAPI |
| Image Enhancement | BLC, HLC, 3D DNR |
| Communication Interface | 1 x RJ45 10/100M self-adaptive Ethernet port |
| Basic Events | Motion detection, video tampering alarm, exception |
| Power Supply | 12 V DC ±25%, reverse polarity protection; PoE: IEEE 802.3af |
| Material | Metal & Plastic |
| Protection | IP67 |
